The heat exchanger of the Quick B3 Nautic Boiler is made of 316-grade stainless steel. The tank itself is 1.5mm thick, and welded in a protected atmosphere of Argon gas, making it particularly resistant to corrosive agents.

Thermal insulation is assured by a high-density polyurethane foam with closed cells, providing better and longer-lasting thermal retention.

The heat exchanger has a capacity that is notably higher than that achieved from other manufacturers.

The heating element is made of Incoloy®, a nickel-based superalloy that has ,excellent corrison-resistance and withstands high temperatures.

The thermal insulation is high-density polyurethane foam injected between the cover and tank to give excellent heat-retention properties.

The 15L, 20L and 25L waterheaters are avaialble with either 500W or 1300W heating element, the other larger capacities are supplied with a 1300W heating element.

Casing in composite material Tank in stainless steel AISI 316

Tank mounting brackets or wall or floor-mounted are in stainless steel AISI 316 and are supplied as standard in each package.

Features

• High-quality materials ensure the product is both reliable and long-lasting
• Heat exchanger with a large exchanging surface
• Producing hot water also by means of an electric element, which is provided with an adjustable and safety thermostat
• Relief/non-return valve protects the tank against overpressure and drains off water from the boiler when no longer used
• Australian compliant pressure/temperature relief valve and thermostatic mixing valve.
• Installation is easy and practical on a flat area

Specifications

Tank Material: Stainless Steel

Thermal Insulator: Polyurethane Foam

External Cladding Material: Composite

Tank Pressure (Running Test): 800kPa*

Maximum Working Pressure: 600kPa*

Electric Element Voltage Rating: 220 Vac ± 10%

Electric Element Power: 500W or 1300W

Output Diameter: 1/2"

Capacity
